P1.86 LED Indoor Rental Video Wall
Model Number: P1.86-43S
Module size: 320*160mm
Pixel pitch: 1.86mm
Pixels Density: 289050dot/m2
Pixel configuration: 1R1G1B
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
P1.86 Indoor Full Color Display SMD1515(1R1G1B)
Unit Module | Item | Parameter |
Model Number | P1.86-43S | |
Module size | 320*160mm | |
Pixel pitch | 1.86mm | |
Pixels Density | 289050dot/㎡ | |
Pixel configuration | 1R1G1B | |
Package mode | SMD1515 | |
Pixel resolution | 172dots(W)* 86dots(H) | |
Best viewing distance | 2M～20M | |
Panel current | 3.5-4A | |
Max Power | 20W | |
Module thickness | 14.7mm | |
Weight | 0.369KG | |
Drive type | Constant drive | |
Scan mode | 1/43Scan | |
Port type | HUB75E | |
Brightness of white balance | ≥600cd/㎡ | |
Refresh frequency | ≥1920HZ |
High refresh and high brightness: the picture is stable, smooth and realistic, and the response speed is fast
Small spacing led box proportion 16:9 gold ratio, is the proportion of human eye pupil, audience can enjoy visual feast
Computer and mobile phone control, dual support, screen + data cloud + app, WiFi networking;
Refresh rate up to 3840hz, stable performance, no flicker, good display effect.
High contrast and wide viewing angle °， Highlight and dazzle color to attract eyes;
It adopts highly integrated design, saving 50% compared with traditional screen.
The screen is small in volume, light in weight, high density full color screen in the house, showing fine and realistic images. The surface paste packaging technology, uniformity, brightness, good perspective, fast installation and disassembly are realized, saving your precious time and labor cost.
Low refresh
High refresh
Our Package
The packaging is made of high-quality cartons, the module is equipped with corner protector, and the pearl cotton corner protector is included, so as to effectively avoid product damage caused by collision during transportation.
FAQ
1:Which pixel pitch should i choose?
In usually,
For indoor stage will be select indoor die casting P2.5 P3 P4 ,P2.976 P3.91 P4.81.
For outdoor stage will be select P4.81 P6.25 P6 P8 P10.
For fixed installed led screen, can select P3 P4 P5 P6 P10.
For outdoor fixed installation,if it is not directly to sun,can select outdoor SMTP6 P8 P10,DIP P10 P16, if directly to sun,can select outdoor SMT P8, DIP P10.
For big size led screen can select SMT P8,SMTP10,SMT/DIP P16.Also we have researched outdoor high resolution SMD 3in1: P4 P5 P6 P8 P10,there are good for high resolution led screen.
2.I wonder know your IC?
We have SM 2K 4K,MBI 2K 4K and ICN three IC for you to choose and use.Of course you can have your IC if you want it.
3: Can you tell me why should I choose your company?
Concentration makes professional .Professional achieves successful . Royal Display Technology has over 10 years professional led technical experience. Now ,we are largely expanding our international market. We can cooperate from trial order to establish trust step by step.
